3-2
Chapter 3. MOUNTING AND WIRING
CAUTION
Before connecting pipes with Swagelok or VCR connections, check the precautions
in the instruction provided by the connecting joint manufacturer.
When purchasing a connecting joint, use the following made by Swagelok Co., Ltd:
1/4" Swagelok: SS-400-1-6STSC11
1/4" VCR: SS-4-VCR-1-00032SC11
The device is a precision instrument. Do not drop it or subject it to impact, or it
might be damaged.
Mounting
z Installation locations
Avoid mounting the device in the following locations:
• Locations subject to high and low temperature and humidity
• Locations whose atmospheres contain large amounts of dirt and
dust, salt, conductive substances such as iron powder, water droplet,
oil mist or organic solvents
• Locations subject to direct sunlight and rain
• Locations directly subject to mechanical vibration or shock
• Locations close to sources of electrical noise
• Locations where strong magnetic or electrical fields are generated
Handling Precautions
•
The valve of this device cannot completely shut a flow off. If com-
plete shutoff is required, provide a shutoff valve separately.
z Changing the display direction (models with integrated display only)
The display can be turned 180°, in case the controller has been
mounted with the display upside-down.
• Procedure
(1) Turn the power OFF.
(2) Remove the four screws holding the display.
To Next Page
