Azbil Corporation Installation
Model PTG60/70/71/72 - Smart Pressure Transmitter 2-7
PTG
Warm
the water
condensate
PTG
Condenser
For condenser For siphon
PTG
Steam Liquid
A
A
B
AB
AB
B
Wet gas Dry gas
PTG
PTG
PTG
PTG
PTG
PTG
Note:
A: The PTG is installed below the pressure outlet.
B: The PTG is installed above the pressure outlet.
Main valve, Gauge valve
Air release valve, Drain valve
Black part of The desirable direction of the pressure outlet
Condenser
Condenser
Siphon
Thermal insulation work
Figure 2-5 Pressure output direction and method of connecting impulse pipes
