Page #12 background imageLoading...
Page #12 background image
E4
MAINTENANCE
Cleaning:
When wiping out the SDC25/26, use the soft and dried
cloth. Do not use a detergent or an organic solvent like
thinner or benzene.
Parts replacement: Do not replace the parts.
Fuse replacement: On AC models, when replacing the fuse for the power,
make sure that the replacement fuse complies with
applicable standards. Use a time lag fuse (T) compliant
with IEC127 and rated at 250V, 0.5A.
MODEL SELECTION TABLE
Basic
model
No.
Mounting Control
output
PV
input
Power
supply
Optional
functions
Additional
processing
Specifications
1 2
1 2
C25 48 × 96 size model
C26 96 × 96 size model
T Panel mounting type
Control output 1 Control output 2
R0 Relay contact output
N.O.
None (relay
output for control
output1: N.C.)
V0
Voltage pulse output*
1
VC
Voltage pulse output*
1
Current output
VV
Voltage pulse output*
1
Voltage pulse output*
1
C0 Current output
CC Current output Current output
U Universal
A AC model (100 to 240VAC) 50/60Hz
D DC model (24VAC/24V DC)
1 Event relay output: 3 points
2 Event relay output: 3 points, Auxiliary
output (current output)
*2 4 Event relay output: 2 points, (independent
contact)
*2 5 Event relay output: 2 points (independent
contact), Auxiliary output (current output)
0 None
*3 1 Current transformer input: 2 points
Digital input: 4 points
*3 2 Current transformer input: 2 points
Digital input: 4 points
RS-485 communication
0 No additional treatment
D Inspection certificate provided
*1.
For SSR drive
*2. Can not be selected for DC model.
*3. Current transformer is sold separately.
Y Complying with the traceability certificate
0 None
A UL-marked product
SPECIFICATIONS
z PV input
Thermocouple:
K, J, E, T, R, S, B, N (JIS C1602-1995)
PL II (Engelhard Industries Data (ITS90))
WRe5-26 (ASTM E988-96 (Reapproved 2002))
Ni-Ni·Mo (ASTM E1751-00)
PR40-20 (Johnson Matthey Data)
DIN U, DIN L (DIN 43710-1985)
Gold iron chromel (Hayashidenko Data)
Resistance temperature detector (RTD):
Pt100 (JIS C1604-1997)
JPt100 (JIS C1604-1989)
DC voltage:
0 to 10mV, −10 to +10mV, 0 to 100mV,
0 to 1V, 1 to 5V, 0 to 5V, 0 to 10V
DC current:
0 to 20mA, 4 to 20mA
Sampling cycle:
300ms
Indication accuracy:
±0.3%FS±1digit, ±0.6%FS±1digit for a
negative area of the thermocouple (at ambient
temperature 23±2°C)
Allowable input:
−0.5 to +12V (thermocouple, RTD, DC,
voltage)
30mA max. or 4V max. (DC current)
More than the allowable input voltage or cur-
rent may damage this device.
z Digital input
Number of input points: 4 points
Input type:
Dry contact or open collector
Allowable ON contact resistance:
Max. 250Ω
Allowable OFF contact resistance:
Min. 100kΩ
Allowable ON residual voltage:
Max. 1.0V
Terminal current (ON):
Approx. 7.5mA (in case of short circuit).
Approx. 5.0mA (in case of contact resistance
250Ω)
Minimum hold time:
600ms or more
z Current transformer input
Number of input points:
2 points
Input object:
Current transformer with 100 to 4,000 turns
(availability is by 100-turn units)
Current measurement lower limit:
0.4A AC (800 turns, 1 time)
Formula; Number of turns ÷ (2000 × number
of power wire loops)
Current measurement upper limit:
50.0A AC (800 turns, 1 time)
Formula; Number of turns ÷ (16 × number of
power wire loops)
Allowable measured current:
70.0A AC (800 turns, 1 time)
Formula; Number of turns ÷ (16 × number of
power wire loops) × 1.4
Display range lower limit:
0.0A AC
Display range upper limit:
70.0A AC (800 turns, 1 time)
Formula; Number of turns ÷ (16 × number of
power wire loops) × 1.4
Display accuracy:
±5%FS
Display resolution:
0.1A AC
z Control Output
• Relay output
Contact rating:
Control output 1: N.O. contacts,
250VAC/30VDC, 3A (resistive load)
Control output 2: N.C. contacts,
250VAC/30VDC, 1A (resistive load)
Life: N.O. contacts, 50,000 cycles min.
N.C. contacts, 100,000 cycles min.
Min. switching specifications: 5V, 100mA
Min. open/close periods: 250 ms
• Voltage pulse output (for SSR drive)
Open circuit voltage:
19VDC±15%
Internal resistance: 82Ω±0.5%
Allowable current:
Max. 24mA DC (a higher current might cause
output circuit failure)
Min OFF time/ON time: 1ms when the time proportional cycle time is
less than 10s.
250ms when the time proportional cycle time
is more than 10s.
• Current output
Output type:
0 to 20mA DC or 4 to 20mA DC
Allowable load resistance: Max. 600Ω
Output accuracy: ±0.1%FS (at ambient temperature 23±2°C)
±1%FS at 0 to 1mA
z Auxiliary output
Output type:
0 to 20mA DC or 4 to 20mA DC
Allowable load resistance:
Max. 600Ω
Output accuracy:
±0.3%FS (at ambient temperature 23±2°C)
±1%FS at 0 to 1mA
z Event relay outputs (ev1 to ev3)
Contact rating:
250VAC/30VDC 2A (resistive load)
Life:
100,000 cycles min.
Min. switching specification:
5V, 10mA (reference value)
z RS-485 communication
Transmission line:
3-wire system
Transmission speed:
4800, 9600, 19200, 38400bps
Communication protocol:
CPL and Modbus conforming
Terminating resistor:
Do not connect a terminating resistor.
z Environmental condition
• Operating conditions
Ambient temperature:
0 to 50°C (Gang-mounting: 0 to 40°C)
Ambient humidity:
10 to 90%RH (non-condensing)
Rated power supply voltage:
AC model 100 to 240VAC, 50/60Hz
DC model 24VAC 50/60Hz, 24VDC
Power supply voltage range:
AC model 85 to 264VAC, 50/60±2Hz
DC model 21.6 to 26.4VAC, 50/60±2Hz
21.6 to 26.4VDC
• Transport conditions
Ambient temperature:
–20 to +70°C
Ambient humidity:
10 to 95%RH (non-condensing)
z Other specifications
Power consumption:
Max. 12VA for AC model
Max. 12VA for DC model at 24VAC
Max. 8W for DC model at 24VDC
Non-detected failure time:
Max. 20ms (AC model)
No power failure allowed (DC model)
Altitude:
2000m or less
Mass:
C25 Approx. 250g (with mounting bracket)
C26 Approx. 300g (with mounting bracket)
Terminal screw tightening torque:
0.4 to 0.6N·m
Applicable standards:
EN61010-1,
EN61326-1 (For use in industrial locations)
During EMC testing, the reading or output
may fluctuate by ±10%FS.
Over-voltage category:
Category II (IEC60364-4-443, IEC60664-1)
Allowable pollution degree:
Pollution degree 2
ACCESSORIES
Name Model No.
Mounting bracket 81409654-001 (Accessory)
