ADSL2+ Ethernet USB Combo Router - User Guide
Page 12 of 42
Chapter 4- Setting Up the ADSL Router
This section will guide you through your ADSL Router’s configuration. The ADSL Router is
shipped with a standard PPP configuration.
The basic tabs consist of features which are catered for basic users.
3.3 Logging into your ADSL Router
To configure your ADSL Router, open your web browser. You may get an error message at this
point; this is normal. Type the default IP address (192.168.1.1) or login.router on the web
address bar.
NOTE: Before setting up your ADSL Router, make sure you have followed the
easy start guide. You should have your computers configured for DHCP
mode and have proxies disabled on your browser. Upon accessing the
ADSL Router, if the browser still displays a login redirection screen, you
should check your browser's setting and ensure that the JavaScript support
is enabled. If the screen shown in Fig 1-4 is not attainable, you must
delete your temporary Internet files to clear the web cache.
Upon entering the default IP address or the short-cut name (login.router), if the user is logging
for the first time, the user will be brought to the “Quick Start” page. See Fig 1.4. The Quick Start
page is meant for basic users whom only require easy connectivity to the Internet without
worrying about any other advance configuration setting. If you are in doubt for what content to
enter for the Protocol, VPI and VCI, please contact your Service Provider for assistance.
Figure 1-4 : Quick Start
