ADSL2+ Ethernet USB Combo Router - User Guide
Page 8 of 42
Chapter 2 – ADSL Ethernet Router Description
The ADSL2+ Ethernet & USB Combo Router is the perfect high-speed WAN bridge/router.
This full-featured product is specifically designed to connect to the Internet and directly connect
to your local area network via high speed 10/100 Mbps Ethernet. The ADSL Router has also full
NAT firewall and DMZ services to block unwanted users from accessing your network.
For game users, the ADSL Router had already pre configured for several low latency game ports.
Just click on the game you are playing on line and the rest is done for you.
The ADSL Router is fully compatible with all PCs; as long as the PC supports an Ethernet
interface and is running a TCP/IP protocol stack, your PC can have high-speed WAN access.
So, plug in the ADSL Router (refer to easy start guide), configure it (per your ISP’s
requirements) and enjoy the fast Internet access like never before.
2.1 ADSL Router Overview
Fig 1-1 shows the system configuration diagram of a typical ADSL Router connection.
Figure 1-1 : ADSL Router Configuration Diagram
USB
Computer/Notebook with
Ethernet Network Card
Computer/Notebook with
USB Port
