Determining Connection Rate
Each LED color of the Powerline Activity represents a connection rating. The connection rating
can only be calculated when the device is part of an existing network. The exact connection rate
value can also be viewed using HomePlug AV Utility.
Good (Red)
Better (Amber)
Best (Green)
Connection rate is
less than 30 Mbps
Connection rate is
between 30 to 80 Mbps
Connection rate is
more than 80 Mbps
Power Saving Mode
After 15 minutes without Ethernet activity, ALL LEDs are in
steady color HomePlug AV is on a Power saving status.
