To create a Secured HomePlug AV network using Simple Connect:
Step 1
Plug your HomePlug AVs side by side where you can easily observe the LED behavior.
Upon connection, the LEDs will blink simultaneously and then the Power LED lights on
steadily.
Press the Simple Connect button of the HomePlug AV X for ten seconds. All LED will blink
indicating that the Private Network Name has been randomize.
Press the Simple Connect button of the HomePlug AV Y for ten seconds. All LED will blink
indicating that the Private Network Name has been randomize.

Aztech HomePlug AV Specifications

General

Standard	HomePlug AV
Interface	Ethernet
Encryption	128-bit AES
Operating Temperature	0°C to 40°C
Data Transfer Rate	200 Mbps
Range	300 meters
Plug Type	Varies by region (EU, UK, US)
Operating Humidity	10% to 90% (non-condensing)
