Aztech HomePlug AV User Manual

User Manual
Page 26 of 44
Setup the HomePlug AVs
For Twin Pack
HomePlug AVs from a Twin Pack are preconfigured to have a common Private Network
Name unique for that pair. All you need to do is connect the HomePlug AVs to an
Ethernet device and then plug it to a wall socket.
To setup a pair of HomePlug AVs:
1. Plug one end of the Ethernet cable to your Ethernet device and then connect the
other end to HomePlug AV.
2. Connect the HomePlug AV to a wall socket.
3. Plug one end of the Ethernet cable to your other Ethernet device and then
connect the other end to HomePlug AV.
4. Connect the HomePlug AV to a wall socket.
For Single Pack
A HomePlug AV from a single pack uses a random Private Network Name that prevents it
from communicating with other HomePlug AVs. To add it into an existing network, you
need to use either the Simple Connect button or the HomePlug AV Utility software to
change the random Private Network Name to the Private Network Name being used by
the existing HomePlug AV network.
To add a HomePlug AV to an existing network:
1. Plug one end of the Ethernet cable to your Ethernet device and then connect the
other end to HomePlug AV.
2. Connect the HomePlug AV to a wall socket.
3. Add the new HomePlug AV by using either Simple Connect or the HomePlug AV
Utility software. To use Simple Connect, please refer to Joining an Existing
HomePlug AV Network. To use HomePlug AV Utility, please refer to Private
Network Name.

Aztech HomePlug AV Specifications

General

Standard	HomePlug AV
Interface	Ethernet
Encryption	128-bit AES
Operating Temperature	0°C to 40°C
Data Transfer Rate	200 Mbps
Range	300 meters
Plug Type	Varies by region (EU, UK, US)
Operating Humidity	10% to 90% (non-condensing)
