Aztech HomePlug AV User Manual

User Manual
Page 8 of 44
Label
LabelLabel
Label Status
StatusStatus
Status Description/ Function
Description/ FunctionDescription/ Function
Description/ Function
A
Filtered AC Pass
Filtered AC PassFiltered AC Pass
Filtered AC Pass-
--
-Through
ThroughThrough
Through Built in AC Pass-through with Powerline Noise Filtering.
Frequency band 2-30Mhz with filtering characteristics of
-25 to -45dB. It prevents noise-generating appliances
from affecting your HomePlugAV's performance.
Only a *BS1363 plug can be plugged into socket outlet.
Blinking
slowly
When LED is blinking slowly in Green color HomePlug
AV is on a Power Saving status.
Off No power.
B
Power
PowerPower
Power
On • After Simple Connect is pressed for two
seconds, this LED will blink to confirm the
button press.
• When Simple Connect is pressed for 10
seconds, this LED will blink to confirm the
Private Network Name reset.
Off Device is not connected to a HomePlug AV network.
C
Powerline Activity
Powerline ActivityPowerline Activity
Powerline Activity
On • This LED remains on when the device is part of
a HomePlug AV network.
• The LED colors represents the connection rate
within the HomePlug AV network whether it is
good (red), better (amber), or best (green).
• The LED flashes to indicate network activity.
Off An Ethernet device is not connected.
D Ethernet Activity
Ethernet ActivityEthernet Activity
Ethernet Activity
On • An Ethernet device is connected.
• The LED flashes to indicate Ethernet activity.
E
Simple Connect Button
Simple Connect ButtonSimple Connect Button
Simple Connect Button Press to create or join a HomePlug AV network. It can
also be used to reset the Private Network Name to a
random key.
F
Ethernet Port
Ethernet PortEthernet Port
Ethernet Port Accepts either cross or straight Ethernet cable.
G
Reset Button
Reset ButtonReset Button
Reset Button Press for 2 seconds to reset to the factory default
settings. When you reset to the factory default, all your
configuration changes will be removed.

Aztech HomePlug AV Specifications

General

Standard	HomePlug AV
Interface	Ethernet
Encryption	128-bit AES
Operating Temperature	0°C to 40°C
Data Transfer Rate	200 Mbps
Range	300 meters
Plug Type	Varies by region (EU, UK, US)
Operating Humidity	10% to 90% (non-condensing)
