2.3 Appropriate Applications
The HVA test instrument is designed to perform high voltage insulation testing of
various types of highly capacitive loads.
Appropriate DUTs
DUT Type Examples
Cables
• Extruded cables (e.g. XLPE)
• Laminated cables (e.g. PILC)
• Insulated cables
• Cable jacket/sheath
Other highly
capacitive loads
• Generators
• Switchgear
• Transformers
• Rotating machines
• Insulators
• Bushings
Appropriate measurements
Measurement Examples
Test
• Capacitance
• Resistance
• Dielectric breakdown voltage
• RMS current
• Applied voltage
2.4 Operator Qualifications
HVA operators must be qualified electrical technicians! Proof of required
qualifications for working in high voltage domain is mandatory. It is highly
recommended that operators have completed an emergency rescue-training
program.
NOTICE
Other
applications
Before proceeding, contact
b2 to validate appropriate use!
