B2 HVA34 - General Description; 3.1 Technical Specifications

3
General Description
12
DHV0078 b2 EN
© b2 electronic GmbH
3 General Description
3.1 Technical Specifications
Characteristic
1
HVA30-5 HVA34 HVA60
Article number SH5004 SH5006 SH5014
Input supply voltage 110-240 V; 50/60 Hz; ± 10%
Input supply power 1.5 kVA 400 VA 1.5 kVA
max. output
voltage
VLF sine wave
23 kV
rms
33 kV
peak
24 kV
rms
34 kV
peak
44 kV
rms
62 kV
peak
VLF square wave 30 kV 34 kV 60 kV
DC [+/-] 30 kV 34 kV 60 kV
resolution: 0.1 kV, accuracy: ± 1%
max. output current
60 mA
rms
10 mA
rms
26 mA
rms
resolution: 1 µA, accuracy: ± 1%
Resistance range 0.1 MΩ….5 GΩ
Output frequency
0.01 Hz-0.1 Hz in steps of 0.01 Hz (default 0.1 Hz) –
auto frequency selection
Sheath test
max. test voltage: 10 kV, duration: 1 min-15 min
trip current: 0.1 mA-5.0 mA
Sheath fault location mode
2
max. test voltage: 10 kV, duration: 1 min-60 min
pulse/period: 1:3 / 4 s, 1:5 / 4 s, 1:5 / 6 s, 1:9 / 6 s
Frequency optimization Yes
Output load
capacity
at 0.1 Hz 3.8 µF 0.5 µF 1 µF
at reduced
frequency/voltage
15 µF 12 µF 10 µF
Metering
voltage and current (true rms and/or peak),
capacitance, resistance, time, flashover voltage
Output duty Continuous! No thermal limitation for operating time.
Test modes manual & automatic
Output modes
AC (VLF) symmetrical and load independent across full range,
DC (plus or negative polarity), burn/fault condition or
fault trip mode, jacket/sheath testing
Safety
Dual discharge
device (internal)
3
50 Hz-12 kV feedback protection/
dual discharge device (internal)
Computer interface RS232 & USB flash memory module
Record storage
Built-in memory: up to 50 reports, 40 test sequences
USB memory flash drive: unlimited
PC software [included] b2 ControlCenter for Windows
Weight 45 kg 19.5 kg 57 kg
Dimensions
4
(mm) L x W x H 450 x 340 x 520 430 x 250 x 360 450 x 340 x 520
Environment
Storage temperature -25°C to 70°C
Operation temperature -10°C to 50°C
Humidity 5-85% non-condensing
