Water Connection
The water connection (fig.2 item1) is
configured for 3/8" hose (ID 10mm).
The hose should be led from the top
down to the machine and secured to
the hose tail by means of a hose clip.
Water pressure should be a between
1 to 5 bar (15 to 75 psi)
1
Fig 2
