Adjustment of the knife-drive support bracket
Prior to working on the machine switch the main electrical switch to the 0
position and lock it. Failure to comply may result in serious personal injury or
death.
Loosen do not remove the 2 hexagon bolts (fig.9A and 9B Items 1 and 2).
(continued on next page)
1
2
Fig 9 A
Fig 9 B
