Cam alignment position
Prior to working on the machine switch the main electrical switch to the 0
position and lock it. Failure to comply may result in serious personal injury or
death.
The upper 2 cams have a setting
mark on the uppermost side of the
cam.
The setting mark for the lowest cam
is located on the underside of the of
the cam support.
