Remove the fuse-holder located under the
rack (3) near the power socket, using a flat
screwdriver.
Changing voltage
Remove the voltage selector, then switch it to the required voltage.
Then change the two fuses depending on the new voltage.
100 V and 120 V fuses = 3.15 A T
220 V and 240 V fuses = 1.6 A T
In case of doubt, call the BABOLAT After-Sales Service Centre.
Changing fuses
Type of fuse: HPC 5x20 mm ceramic
BE CAREFUL: in the event of a problem, you should change both fuses at the same time.
The warranty will be invalidated by the use of any fuses other than those
recommended by BABOLAT.
3
13
