BabySense 7 - Troubleshooting Guide; Control Unit & Battery Issues; False Alarm Troubleshooting; Alarm Activation Issues

4
• Baeries are not inserted
correctly or may be flat.
• Check baeries are inserted in the Control Unit observing the
correct polarity.
• Control Unit requires 4 X AA 1.5V Alkaline baeries (not supplied).
• Baeries low. • If red low-baery warning light flashes, replace all baeries as
soon as possible. If in addion clicking is heard, all baeries must
be replaced immediately.
• Sensor pad is out of order.
• Cable is connected to monitor’s
blocked socket.
• Connect one sensor pad and lay the baby on the bed for 1 minute. If
the alarm does not acvate, the sensor pad is in order. If the alarm
acvates, disconnect and place the sensor pad aside.
• Connect the other sensor pad and repeat steps above.
• Do not connect any cables to the blocked socket
(only to “SENSOR” socket).
• The maress is not
touching the sensor pads.
• Make sure that the maress and the sensor pads are touching.
• The maress is raised
(there is an object near the
sensor pads).
• Make sure that there are no objects next to the sensor pads.
• Placing two sensors next to each
other (or using one sensor) when
the baby is of crawling age or
using two sensor pads far apart
from each other when baby is
young and is not crawling yet.
• Connect according to instrucons.
• It is important to use only one sensor pad when the baby is young
and is not crawling yet.
• It is important to make sure that two sensor pads are used when the
baby is moving around.
• Make sure the sensor pads are placed underneath baby’s
locaon in bed / crib.
• The maress does not enable
transfer of baby movements (a rigid
maress, a maress with springs or
a maress with air pockets).
• So or spring bed / crib base.
• Place extra plywood under the sensor pad so that the
sensor pad and the maress will be ghtly pressed together.
• Performance test is not correct. • Do not conduct performance test by taking the baby out of bed
and waing for the alarm to sound. Kindly conduct performance
test according to guidance in page 3.
Soluon
Possible Cause
Symptom
Lights on Control Unit
don’t illuminate when
turned ON
Low baery voltage
warning (red light) on
the Control Unit
False alarm up to 1/2
minute from
acvang
False alarm aer 1/2
minute from
acvang
Delayed alarms while
taking the baby out of
the bed
• Environmental influences
detected by the sensor pads,
such as wind, fan, air condioner,
baby mobile toy, vibraons.
• Perform a test which will detect the source of the movement that
the device detects. For example, sources of wind such as: air
condioner, an open window or a fan; movements of a baby mobile
toy (which can vibrate even if it's not turned on) or walking around the
bed area. Soluons: Eliminate sources of wind, remove the mobile toy
etc. Aer neutralizing all environmental influences, perform the test
again. If even aer neutralizing all of the environmental influences, the
alarm does not go off within 20 seconds, perform the following:
1. Test the control unit:
- Disconnect all cables from the control unit.
- Turn control unit on (with no cables aached).
- Alarm acvaon within 20 seconds indicates that the unit is OK –
proceed to the next steps.
- If the alarm does not sound within 20 seconds, stop using the device
and contact your local distributor.
2. Test each sensor pad separately:
- Connect one sensor pad to either “SENSOR” socket on control unit.
- Turn control unit on and take two steps back from the bed.
- Alarm acvaon within 20 seconds indicates that the sensor is OK –
perform the above procedures with the second sensor pad.
- If the alarm does not sound within 20 seconds,
place the sensor pad aside.
Note: If one of the sensor pads is NOT OK, connue using the product
with only the one correctly funconing sensor. If one or both sensors
are NOT OK, contact your local distributor for further guidance.
3. Test two sensor pads together:
- If both sensors were OK in Step 2, connect both sensors to “SENSOR”
sockets on the control unit.
- Turn control unit on and take two steps back from the bed.
- Alarm acvaon within 20 seconds indicates that the sensors are OK
- connue using the product.
- If the alarm does not sound within 20 seconds, connect one sensor
only and connue using the product. Contact your local distributor
for further guidance.
The alarm does not go
off within20 seconds
when performing the
correct
performance test
Troubleshooting Guide
