MGS Series Controller Manual

10 6709-9000 Rev 1

NOTE: Figure 4 shows components associated with a dual-

alarm configuration. For single-alarm configurations, the Low

Alarm LEDs are not present. JP1 on the single-alarm

configuration is the delay jumper.

Figure 5. 2-Channel, Dual-Alarm MGS Controller

NOTE: Figure 5 shows components associated with a dual-

alarm configuration. For single-alarm configurations, the Low

Alarm LEDs are not present, and the Delay Jumper will be

present. The Delay Jumper is not available on dual-alarm

configurations, though its location is highlighted above.
