5
BF-UM-C-DP C010-EN November 2022
USER MANUAL FOR DISPLAY
7.6 NORMAL OPERATION
7.6.1 Power ON/OFF
Press and hold (>2S) to power on the HMI, and the HMI displays the boot up LOGO.
Press and hold (>2S) again to power off the HMI.
7.6.2 Power-Assisted Mode Selection
When HMI powers on, briefly press or (<0.5S) to select the power-assisted mode and
change the output power of motor. 4 Modes or 6 Modes can be selected, but the default selection is
6 Modes of which the lowest mode is ECO and the highest mode is BOOST. The default mode is ECO
after HMI powering on, mode OFF means no power assistance.
(6 Modes)
(4 Modes)
