BAFANG Ebike Essentials 500C - Overview Drawing and Hardware; Display Unit and Mounting Hardware

OVERVIEW DRAWING/HARDWARE
OVERVIEW DRAWING
3
500C MANUAL© Copyright Ebike Essentials. All Rights Reserved.
www.Bafangusadirect.com
Do not over tighten the display bracket bolt or it may crack the plastic!
HARDWARE
Display Unit
1
M4 0.7 x 10mm Bolt
(Display Bracket Bolt)
2
80
17.5
Φ22
41
