LIBRA FREESTANDING
INSTALLATION INSTRUCTIONS
LIBRA - installation
www.bainultra.com
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
INSTALLATION WITH ACCESS UNDER THE FLOOR
PVC DRAIN
PVC & BRASS DRAIN
BRASS DRAIN
B-2B-2
B-1B-1
B-3B-3
B-4B-4
B-5B-5
Overflow pipe
PVC Connector
PVC Drain
NOTE: If necessary, cut the overflow pipe to
the desired length, and glue it to the
PVC connector and to the drain.
