LIBRA FREESTANDING
INSTALLATION INSTRUCTIONS
LIBRA - installation
www.bainultra.com
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
REMOTE MOUNTING OF TURBINE
1
TURBINE & GEYSAIR INSTALLATION (FOR THERMOMASSEUR
®
)
WARNING
• Access to Geysair
®
hot water connections is necessary for cleaning of the filter. (Back flow preventor)
• Geysair
®
cannot be remotely installed.
Must never be unplugged.
GEYSAIR HOSE AND
FLOW REGULATOR
FLOW
REGULATOR
HOT WATER SUPPLY
1-1/2 I.D. PVC AIR INTAKE PIPE
(«TIGERFLEX
®
» FLEXIBLE PVC)
1-1/2 I.D. ABS, PVC PIPE
(RIGID or «TIGERFLEX»)
& Fittings (not included)
