LIBRA - installation
LIBRA FREESTANDING
INSTALLATION INSTRUCTIONS
1 800 463.2187 Monday to Thursday from 8 a.m. to 6 p.m. (EST)
.
Friday from 8 a.m. to 5 p.m. (EST)
Printed in Canada. Copyright © August 2021 Bains Ultra Inc. All rights reserved. 45200682
INSTALLATION WITH ACCESS UNDER THE FLOOR
Anchor
M
2
BATH INSTALLATION
HELPFUL TIPS:
• Carefully place the tub on its side,
on a blanket or a corrugated cardboard.
• To easily manipulate the bathtub
in a safe way during installation,
we recommend using
moving straps.
1“ Maximum
Floor
surface
STEPS TO FOLLOW
• Do not remove the protective plastic film on the tub
and place a drop-cloth in the tub during installation
to protect the acrylic.
• Be sure the floor is leveled. Use shims as needed.
• Connect the drain.
• Apply a bead of silicone at the perimeter
of the bath once on the floor.
Measure & Align
Anchor Holes (2x)
To Next Page
