Balluff BNI007Z - Safe State of the Outputs on Pin 2 43 Hex

Balluff Network Interface / IO-Link BNI IOL-302-002-K006
www.balluff.com
14
4 Configuration: "Extension Off"
Safe state
of the
outputs on
Pin 2 43hex
Byte
0
1
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Sub-
index
4
3
2
1
8
7
6
5
Description
Safe state Port 3 Pin 2
Safe state Port 2 Pin 2
Safe state Port 1 Pin 2
Safe state Port 0 Pin 2
Safe state Port 7 Pin 2
Safe state Port 6
Pin 2
Safe state Port 5 Pin 2
Safe state Port 4 Pin 2
Value
Output state
bin
dec
00
0
Output is 0V
01
1
Output is 24V
10
2
Current status is maintained
11
3
Not defined
