6 Configuration extended with Valve Terminal Connector with 22/24 Valves
Safe state of
Outputs 42hex
The safe state parameter makes it possible to configure the outputs in case of a fault. If no IO-
Link communication is possible or the "valid flag" of the output process data has not been set
by the master, then each output adopts the configured status. The following statuses can be
configured for each pin.
Safe state of
the Outputs Pin
4, 42hex
Byte
0
1
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Sub-
index
4
3
2
1
8
7
6
5
Description
Safe state Port 3 Pin 4
Safe state Port 2 Pin 4
Safe state Port 1 Pin 4
Safe state Port 0 Pin 4
-
Safe state Port 6 Pin 4
Safe state Port 5 Pin 4
Safe state Port 4 Pin 4
Byte
2
3
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Sub-
index
31
29
27
25
Valve terminal on the extension port
Description
-
-
-
-
* Valve 12
Coil A
Valve 11
Coil A
Valve 10
Coil A
Valve 09
Coil A
* No function for V013
Byte
4
5
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Sub-
index
23
21
19
17
15
13
11
9
Valve terminal on the extension port
Description
Valve 08
Coil A
Valve 07
Coil A
Valve 06
Coil A
Valve 05
Coil A
Valve 04
Coil A
Valve 03
Coil A
Valve 02
Coil A
Valve 01
Coil A
