Balluff BNI007Z User Manual

Balluff Network Interface / IO-Link BNI IOL-302-002-K006
www.balluff.com
38
8 Technical Data
8.1. Dimensions
8.2. Mechanical
Data
Housing material
Plastic, transparent
IO-Link port
IO-Link port M12, A-coded, male
I/O ports
M12x1, A-coded, female (8 piece)
Weight
90 g
Dimension (L × W × H, without
connector)
115 × 50 × 30.8 mm
8.3. Electrical Data
Supply voltage
18–30.2 V DC, corresponding to EN 61131-2
Ripple
< 1%
Current consumption without load
≤ 65 mA
Load current (PIN 1)
Max. 200 mA (temperature-dependent)
Load current per output (PIN 2.4)
Max. 300 mA (temperature-dependent)
Inputs
PNP, type 3
8.4. Operating
conditions
Ambient temperature
-5 °C … +55 °C
Storage temperature
-25 °C … +70 °C
Degree of protection
IP67 (only in plugged-in and screwed
state)
