9 Function Indicators
Digital LED
indicators for
inputs/outputs
LED 2, input/output on Pin 4 and LED 1, input/output on Pin 2
Indicator
Request / Signal
Yellow
Input/output signal = 1
Red
Sensor power supply short-circuit,
actuator warning
actuator short circuit
Off
Input/output signal = 0
Extension
port
The table is valid if the extension port is active. If the extension port is used as a standard I/O,
then the description from "Digital LED indicators for inputs/outputs" can be used.
Status
Function
Green
IO-Link – connection active
Green, flashing
No IO-Link connection or faulty IO-Link device
Red flashing
Incorrect IO-Link device or incorrect configuration
Yellow
Actuator power supply active
