BSP B/M/V _ _ _ - _ _ _ _ _ - P00S2B - S4(- _ _ _ )
Pressure Sensors with IO-Link
With the CE marking we declare that our
products are in conformity with the current
EMCand pressure equipment directive.
File no.
E227256
Intended use
The pressure sensor was developed for pressure
monitoring of gases or liquids which are compatible with
stainless steel, ceramic and fluoroelastomer (FKM).
Depending on the device and mechanical connection,
pressure sensors are suitable for various application areas.
The pressure sensor is intended to be installed into a
machine or system. Flawless function in accordance with
the specifications in the technical data is ensured only
when using original Balluff accessories. Use of any other
components will void the warranty.
Modifications to the sensor or non-approved use are not
permitted and will result in the loss of warranty and liability
claims against the manufacturer.
General safety notes
Installation and startup may only be performed by
trained specialists.
The operator is responsible for ensuring that local safety
regulations are observed. In particular, the operator must
take steps to ensure that a defect in the sensor will not
result in hazards to persons or equipment.
If defects and unresolvable faults occur in the sensor, take
it out of service and secure against unauthorized use.
Downloading further instructions
A complete user’s guide can be downloaded from the
Internet at www.balluff.com or requested via e-mail from
service@balluff.de.
Front flush version (IP67)
BSP_ _ _ _-IV009-P00S2B-S4…
G1/2"
43
BSP_ _ _ _-ZT009-P00S2B-S4-006
2.9
50.5
23
Front flush version (IP67 und IP69K)
BSP_ _ _ _-IV010-P00S2B-S4…
G1/2"
10
43 17 18
BSP_ _ _ _-ZT010-P00S2B-S4…
2.9
50.5
23
Dimensions
Non-front flush version (IP67)
BSP_ _ _ _-EV009-P00S2B-S4…
34
49
30
27
G1/4"
23 17 18 37
M12x1
BSP_ _ _ _-FV009-P00S2B-S4…
30
27
NPT1/4"
23
BSP_ _ _ _-HV009-P00S2B-S4…
G1/2"
39
Triclamp
Triclamp
