Parameterization data
The pressure sensor parameter data corresponds to the smart sensor profile.
Index
hex
Subin-
dex hex
Object name Single Value Default Comment
0x02 0x00 System com-
mands
0x81 = Deleting Min./Max. value (Application reset)
0x82 = res (restore factory settings)
0xA0 = Set0 (set 0 point)
The action is
carried out by
writing in the
subindex.
0x0C 0x00 Device access
lock
0x00: Unlocked
0x01: IO-Link lock
0x02: Data storage lock
0x04: Parameterization lock
0x08: User interface lock
0x03: IO-Link lock + Data storage lock
0x05: IO-Link lock + Parameterization lock
0x09: IO-Link lock + User interface lock
0x06: Data storage lock + Parameterization lock
0x0A: Data storage lock + User interface lock
0x07: Data storage lock + IO-Link lock + Param-
eterization lock
0x0B: Data storage lock + IO-Link lock + User
interface lock
0x00:
Unlocked
Datastorage lock
0x24 0x00 Device status 0x00 Device is operating properly
0x02 Out of specification
0x04 Failure
0x3D 0x02 Switch point
mode
0x80: Hysteresis NO
0x81: Hysteresis NC
0x82: Window NO
0x83: Window NC
0x80: Hno
0x3F 0x02 Switch point
mode
0x80: Hysteresis NO
0x81: Hysteresis NC
0x82: Window NO
0x83: Window NC
0x80: HNo
0x50 0x00 Rotate display 0x01 0°
0x00 180°
0x01: 0°
0xD4 0x00 Unit 0x00 bar
0x01 mbar
0x02 PSI
0x03 MPa
0x00: bar Display pressure
unit is changed,
the IO-Link pro-
cess data is not
changed
