11.1 Accuracy
The specifications are typical values at DC 24 V and room
temperature, with a nominal length of 500 mm in
conjunction with the BTL-P-1013-4R, BTL-P-1013-4S or
BTL-P-1012-4R magnet or with the BTL2-S-6216-8P-Ex,
BTL2-S-5113-4K-Ex, BTL2-S-4414-4Z-Ex or
BTL2-S-4414-4Z01-Ex float.
The BTL is fully operational immediately, with full accuracy
after warm-up.
For special versions, other technical data may
apply. Special versions are indicated by the
suffix -SA on the part label.
Repeat accuracy
Voltage, typical
Current, typical
±10µm
±5µm
Sampling rate
Dependent on nominal length
At nominal length = 500mm
250µs…5.7ms
500µs
Non-linearity at
Nominal length ≤500 mm
Nominal length > 500 to
≤5500 mm
Nominal length > 5500 mm
±50µm
±0.01% FS
±0.02% FS
Temperature coefficient
1)
≤ 30ppm/K
Max. detectable velocity 10m/s
11.2 Ambient conditions
Ambient temperature
Standard
2)
Extended
3)
, SA418
–40…+80°C
–50…+80°C
Storage temperature –50…+85°C
Humidity <90%, non-condensing
Rod pressure rating (when
installed in hydraulic cylinders)
≤600bar
Shock rating
Continuous shock
per EN60068-2-27
4), 5)
100g/6ms
100g/2ms
Vibration
per EN60068-2-6
4), 5)
12g, 10…2000 Hz
Degree of protection per
IEC60529
IP66, IP68
4), 6)
11.3 Supply voltage (external)
Voltage, stabilized: 10…30VDC
Ripple ≤0.5V
ss
Current draw (at24VDC) ≤150mA
Inrush current ≤ 500mA
Reverse polarity protection
7)
Up to 36V
Overvoltage protection Up to 36V
Dielectric strength
(GND to housing)
500VAC
11.4 Output
BTL7-A… Output voltage
Load current
0…10V and 10…0V
≤5mA
BTL7-C… Output current
Load resistance
0…20mA/20…0mA
≤500Ω
BTL7-E… Output current
Load resistance
4…20mA/20…4mA
≤500Ω
BTL7-G… Output voltage
Load current
–10…10 V and 10…–10 V
≤5mA
Short-circuit resistance Signal cable to 36 V
Signal cable to GND
11.5 Input
Programming inputs La, Lb: High-active, 10 to
30VDC
Overvoltage protection Up to 36V
1) Nominal length=500mm, magnet in the middle of the measuring range
2) See approvals on page 6
3) Prerequisite: Nominal length ≤ 2680 mm.
The device must be activated at ≥–40°C.
4) Individual specifications as per Balluff factory standard
5) Resonant frequencies excluded
6) To maintain the IP68 rating, ensure that the connection at the conduit
opening also meets this standard. Thread sealant should be used on the
conduit opening to ensure protection against moisture ingress. Take
measures to prevent the possibility of internal condensation at the
conduit opening from entering the BTL.
7) A prerequisite is that no current can flow between GND and 0V in the
event of polarity reversal.
Ensure power is limited to ≤ 5W!
11
Technical data
BTL7-A/C/E/G5_ _-M_ _ _ _-J-DEXC-TA12
Magnetostrictive Linear Position Sensor – Rod Style
Type of protection “db” and “ta”
Flameproof enclosure
