Balluff BTL7-A5 M Series User Manual

30 english
BTL7 - A 5 10 - M0500 - J - DEXC - TA12
Interface:
A = Analog interface, voltage output 0…10V
G = Analog interface, voltage output –10…+10 V
C = Analog interface, current output 0…20 mA
E = Analog interface, current output 4…20 mA
Supply voltage:
5 = 10…30 V DC
Output gradient:
00 =Rising (e.g. C_00 = 0…20 mA); only with BTL7-C/E
10 =Rising + falling (e.g. A_10 = 10…0 V and 0…10 V); only with BTL7-A/G
70 =Falling (e.g. C_70 = 20…0 mA); only with BTL7-C/E
Nominal length (4-digit):
M0500 = Metric specification in mm, nominal length 500 mm (M0025…M7620)
Rod version, fastening:
J = 6 screws (hole circle 76.2mm)
Plug:
C = Float plug
Electrical connection:
TA12 = Terminal with 1/2"-14 NPT (conduit entry)
Order example for special version (optional, no influence on Ex characteristics):
BTL7-A510-M0500-J-DEXC-SA_ _ _-TA12
13
Type code
BTL7-A/C/E/G5_ _-M_ _ _ _-J-DEXC-TA12
Magnetostrictive Linear Position Sensor – Rod Style
Type of protection “db” and “ta”
Flameproof enclosure
