15
LED and Beeper Indications
34
BVS HS-PB
Industrial Cordless Handheld Barcode Reader
15 LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate various
functions or errors on the reader. The green LED Spot backprojected
on the code provides a reliable feedback to the user. The following
tables list these indications. One exception to the behaviors listed in the
tables is that the reader’s functions are programmable, and so may or
may not be turned on. For example, certain indications such as the
power-up beep can be disabled using programming barcode labels.
Normal Operating Indicators
INDICATION DESCRIPTION LED BEEPER
Power-up
Beep
The reader is in
the process of
powering-up.
N/A
Reader beeps four
times at highest
frequency and vol-
ume upon power-
up.
Good Read
Beep
A label has been
successfully
scanned by the
reader.
LED behavior is
configurable via
the feature
“Good Read:
When to Indi-
cate” (see the
OPM for infor-
mation.)
The reader will
beep once at cur-
rent frequency,
volume, tonal set-
ting and duration
upon a successful
label scan.
Green LED
Spot
a
flashes
momentarily
Upon success-
ful read of a
label, the soft-
ware turns the
green spot on
for the time
specified
N/A N/A
Capture
When ready to
capture image
Blue light
flashes 2 times
when updating
N/A
a Except when in sleep mode or when a Good Read LED Duration other than 00
is selected
