LED and Beeper Indications
36
BVS HS-PB
Industrial Cordless Handheld Barcode Reader
Programming Mode - The following indications ONLY occur when the
reader is in Programming Mode.
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode
Entry
A valid program-
ming label has been
scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode
Rejection of
Label
A label has been
rejected.
N/A
Reader sounds
three times at low-
est frequency and
current volume.
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where mul-
tiple labels must be
scanned to pro-
gram one feature,
this indication
acknowledges each
portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep at
highest frequency
and current vol-
ume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep and
4 low frequency
beeps followed by
reset beeps.
Label Program-
ming Mode
Cancel Item
Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
