148
1.18.6.2 Using mvBlueFOX-MLC with motorized lenses (MotorFocusControl)
1.18.6.2.1 Introduction It is possible to use the -MLC with a motorized lens mount without optical filter. To control
this lens mount you use either wxPropView (p. 68) or the class MotorFocusControl from mvIMPACT Acquire for
your own applications.
This camera option consists of a single-board camera module plus additional interface board. The camera is
equipped with a board-to-wire connector on the interface board for opto-coupled I/O connection and a Mini USB.
Other versions with TTL coupled inputs and outputs and without Mini USB connector are available on demand.
There is no optical filter in the light path. For color applications MATRIX VISION supplies S-mount lenses with IR
absorbing coating.
Important technical data of the motorized lens mount: (Consult MATRIX VISION for more detailed data, application
notes and the full lens command reference manual)
Lens Type (Lens not included), accepts M12x0.5mm, smaller
lenses to M8x0.35 with adapter from your lens supplier
Lens Weight
∗
< 5 grams
Travel Range Up to 1.5 mm
Housing Dimension 20 x 22 x 16 mm
Max Image Sensor Area (image sensor not included) 17 x 17 x 1.25 mm (including 1/2" and 1/1.8" formats)
Speed > 5 mm/s
Resolution 0.5 um
Hysteresis None
Repeatability Uni-directional +/- 5 um
Bi-directional +/- 20 um
Linear Accuracy +/- 30 um
Angular alignment (Static tip/tilt) > +/- 1 degree
Angular movement (Dynamic tip/tilt) > +/- 0.15 degree
Static Concentricity > +/- 0.25 mm
Dynamic Concentricity > +/- 0.02 mm
Input Voltage 3.1 to 3.6 Volts
Input Power
∗∗
< 0.5 Watts (5mm/s with 5g mass)
< 0.13 Watts quiescent
Temperature / RH
∗∗∗
5 ° to 70 °C (lower possible) < 95% RH non-
condensing
Mean Time Before Failure > 2M Cycles (fixed orientation)
500K Cycles (random orientation)
Weight of module (without lens) 5.8 grams
Compliance CE / RoHS
∗
Fixed orientation will allow for heavier lens operation. Consult Matrix Vision if your lens does not fit or cannot
be focused.
∗∗
Power depends on input voltage, speed & load.
∗∗∗
Consult MATRIX VISION if you have for lower
temperature requirements.
MATRIX VISION GmbH
