Balluff MATRIX VISION mvBlueFOX Series User Manual

1.10 Sensor Overview 63
Pipelined in
continuous /
triggered mode
X / - X / - X / - X / - X / -
Flash con-
trol output,
synchronous
to exposure
period
X
More specific
data
mvBlueFOX-
[Model]220
(0.3 Mpix [640
x 480]) (p. 173)
mvBlueFOX-
[Model]220a
(0.3 Mpix [640
x 480]) (p. 178)
mvBlueFOX-
[Model]221
(0.8 Mpix
[1024 x 768])
(p. 183)
mvBlueFOX-
[Model]223
(1.4 Mpix
[1360 x 1024])
(p. 187)
mvBlueFOX-
[Model]224
(1.9 Mpix
[1600 x 1200])
(p. 192)
1
With max. frame rate, image quality losings might be occur.
1.10.2 CMOS sensors
The CMOS sensor modules incorporate the following features:
Sensors: 0.4 Mpixels
resolution
CMOS sen-
sor (-200w)
1.3 Mpixels
resolution
CMOS sen-
sor (-202a)
1.2 Mpixels
resolution
CMOS sen-
sor (-x02v)
1
only -MLC/-
IGC
1.2 Mpixels
resolution
CMOS sen-
sor (-x02b)
1
only -MLC/-
IGC
1.2 Mpixels
resolution
CMOS sen-
sor (-202d)
1
only -MLC/-
IGC
5.0 Mpixels
resolution
CMOS sen-
sor (-205)
Sensor sup-
plier
Aptina Aptina Aptina Aptina Aptina Aptina
Sensor
name
MT9V034 MT9M001 AR0135 MT9M021 MT9M034 MT9P031
Resolution 752 x 480
gray scale or
RGB Bayer
mosaic
1280 x 1024
gray scale
1280 x 960
gray scale or
RGB Bayer
mosaic
1280 x 960
gray scale or
RGB Bayer
mosaic
1280 x 960
gray scale or
RGB Bayer
mosaic
2592 x 1944
gray scale or
RGB Bayer
mosaic
Indication of
sensor cate-
gory to be
used
1/3" 1/2" 1/3" 1/3" 1/3" 1/2.5"
Pixel clock 40 MHz 40 MHz 40 MHz 40 MHz 40 MHz 40 MHz
Max. frames
per second
(in free-
running full
frame mode)
88.6
2
24.6 24.6 24.6 24.4 5.8
Binning H+V (frame
rate 170 Hz)
H+V,
AverageH+V
(frame rate
unchanged)
H+V,
AverageH+V
(frame rate
unchanged)
H+V,
AverageH+V
(frame rate
unchanged)
H+V,
AverageH+V
(frame rate
unchanged)
H+V, 3H+3V,
AverageH+V,
Average3←-
H+3V,
Dropping←-
H+V,
Dropping3←-
H+3V (frame
rate 22.7 Hz)
