1.9 Technical Data 43
State LED
Camera is not connected or defect LED off
Camera is connected and active Green light on
1.9.2.3 Components
FPGA for image processing
pixel clock up to 40 MHz
reliable image transfer
using bulk-mode
image data surrounded by headers
several trigger modes
auto, SW, external
flash control output
using opto-isolated outputs
opto-isolated I/O
2 inputs, 2 outputs on D-Sub 9 connector
bus powered
no external power supply needed
two USB connectors
standard USB or circular plug-in connector 4 pin locked
ambient temperature operation: 0..45 deg C / 30..80 RH
ambient temperature storage: -20..60 deg C / 20..90 RH
Additional features of mvBlueFOX-2xx:
8 Mega-pixel image memory (FiFo)
new ADC
10 Bit mode
