58
• C(S)-mount compatibility using mvBlueCOUGAR-X flange
• ambient temperature operation: 5..55 deg C / 30..80 RH
• ambient temperature storage: -25..60 deg C / 20..90 RH
1.9.5 Single-board version with housing (mvBlueFOX-IGC2xx)
1.9.5.1 Dimensions and connectors
Figure 28: mvBlueFOX-IGC
Lens protrusion C-Mount CS-Mount
X 10 mm 5 mm
Figure 29: mvBlueFOX-IGC-3xxx with adjustable backfocus
Lens protrusion C-Mount
X 8 mm (9.5 mm with max. Ø 20 mm)
Note
The mvBlueFOX-IGC has a serial I²C bus EEPROM with 16 KByte of which 8 KByte are reserved for the
firmware and 8 KByte can be used to store custom arbitrary data.
MATRIX VISION GmbH
