Sensors 0.3 Mpixels
resolution CCD
sensor (-220)
0.3 Mpixels
resolution CCD
sensor (-220a)
0.8 Mpixels
resolution CCD
sensor (-221)
1.4 Mpixels
resolution CCD
sensor (-223)
1.9 Mpixels
resolution CCD
sensor (-224)
Sensor supplier Sony Sony Sony Sony Sony
Sensor name ICX098 AL/BL ICX424 AL/AQ ICX204 AL/AQ ICX267 AL/AQ ICX274 AL/AQ
Resolution 640 x 480
gray scale or
RGB Bayer mo-
saic
640 x 480
gray scale or
RGB Bayer mo-
saic
1024 x 768
gray scale or
RGB Bayer mo-
saic
1360 x 1024
gray scale or
RGB Bayer mo-
saic
1600 x 1200
gray scale or
RGB Bayer mo-
saic
Sensor format 1/4" 1/3" 1/3" 1/2" 1/1.8"
Pixel clock 12 MHz / 24
MHz
20 MHz / 40
MHz
20 MHz / 40
MHz
tbd / 40 MHz 20 MHz / 40
MHz
Max. frames
per second
60 100 39
1
20 16
Binning H+V H+V H+V H+V H+V
Exposure time 44 us - 10 s 26 us - 10 s 44 us - 10 s 33 us - 10 s 30 us - 10 s
ADC (on sen-
sor board) reso-
lution
12 bit (up to
10 bit transmis-
sion)
12 bit (up to
10 bit transmis-
sion)
12 bit (up to
10 bit transmis-
sion)
12 bit (up to
10 bit transmis-
sion)
12 bit (up to
10 bit transmis-
sion)
Programmable
analog gain and
offset
X
Frame integrat-
ing progressive
scan sensor (no
interlaced prob-
lems!)
X
High resolution X
High color re-
productivity (for
color version)
X
High sensitivity,
low dark current
X
Continuous
variable-speed
shutter
X
Pipelined in
continuous /
triggered mode
X / -
Low smear X
Excellent an-
tiblooming
characteristics
X
Programmable
exposure time
from usec to
sec.
X
Programmable
readout timing
with free cap-
ture windows
and partial scan
X
Trigger (Hard-
ware / Soft-
ware)
X / X
