Bambu Lab A1 mini - Organizer Installation; Install Cable Organizer; Secure Black Cable; Route PTFE Tubes

Organizer Installation
① Install the organizer as shown in the diagram.
② Clip the black cable into the smaller hole.
③ The other four holes are for PTFE tubes.
(Recommend distance between A1 mini and AMS lite is 50mm as shown in the diagram.)
Black Cable
50mm
