PanelMax installation instructions
22. Appendix
A - Status Indication during Operating Mode.
LEDs Light Status Indicates
BLUE GREEN YELLOW RED
DOOR OPEN
2
AND
CLOSED
1
LEDS
solid
ashing
ashing
solid
solid
rapid
ashing
ashing
ashing
solid
Open
Open with Autoclose timer running
Opening / Obstructed on Open
Closed
Closing / Obstructed on Close
Stopped
Partial Open
MODE LED
3.
ashing Load Diagnostics mode
REMOTE CONTROL
STATUS LED
4
ashing
rapid
ashing
Remote lockout
Remote Control Activity
04
01
02
03
