PanelMax installation instructions
F - Setting up Tilt Door
Prior to limit set up, the opener can be set to J-Type Tilt Prole. This process allows the opener to pre-set to J-Type
settings where the limit is not greater than 1500mm. If J-Type is selected, the speed is customised and cannot be
changed.
a. Press the MODE button repetitively until the GEAR
LED starts ashing.
b. Press and hold STOP / SET button for 2 seconds to check the door type, until the main courtesy light turns solid
ON or OFF.
• Main courtesy light ON - Tilt type (J-Type only)
• Main courtesy light OFF - Sectional type
c. Press and hold STOP / SET for 6 seconds to change the door type, until the main courtesy light turns solid ON
or OFF. If required, repeat step b to check the door type selected.
d. Press MODE button to exit the door selection mode. Proceed to Section 12 to set the limits.
