Bandit
21
Copyright 4/21
MODELS 2550/2550T
1. Swing Speed Control: The swing speed controls the rate the cutter wheel passes through the stump.
To decrease the swing speed, turn the control knob clockwise.
2. Travel Speed Control: The travel speed controls the rate the machine approaches the stump. To decrease
the travel speed, turn the control knob clockwise.
3. Brake Release Valve: Turn 3 to 4 full revolutions when moving the machine without power.
4. Ignition Switch: Location varies with dierent engine options.
5. Cutter Wheel On / O Switch: Before engaging or disengaging the cutter wheel, make sure the
engine is at an idle. To turn the cutter wheel on, push the switch up. To turn the cutter wheel o, push
the switch down.
6. Steer Right / Left: To steer the machine to the right, push the handle, away from the operator. To steer
the machine to the left, pull the handle, towards the operator. The steering is stationary when the handle
is in the center location.
7. Travel Forward / Reverse: To move the machine forward, push the handle away from the operator. To
reverse the machine, pull the handle towards the operator. The machine is stationary when the handle
is in the center location.
8. Grading Blade Down / Up: To lower the grading blade, push the handle away from the operator. To lift
the cutter wheel, pull the handle towards the operator. The cutter wheel lift is stationary when the handle
is in the center location.
9. Cutter Down / Up: To lower the cutter wheel, push the handle away from the operator. To lift the grading
blade, pull the handle towards the operator. The grading blade is stationary when the handle is in the
center location.
10. Swing Left / Right: To swing the cutter wheel to the left, push the handle, away from the operator. To
swing the cutter wheel to the right, pull the handle, towards the operator. The swing is stationary when
the handle is in the center location.
11. Emergency Stop: Stops the engine in emergency situations.
12. Power Display: Displays engine information: Temperature, RPMs, Tach / Hour Meter, etc.
CONTROL OPERATING PROCEDURES
MANUAL
CONTROLS
