MODELS 2550/2550T FRAME COMPONENTS
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
MODEL 2550T
# Part Number Description
1
900-5916-78 Rubber Track - No Tread
900-5913-05 Rubber Track - With Tread
2
900-5911-26 Small Roller (Start 11/17)
900-5911-26 Small Roller (Pre 11/17)
3 402-3000-14 Top Track Guide
4 900-5911-69 Idler Roller
5 400-3001-24 Idler End Retainer
6 400-2000-07 Front Idler Mount Assembly
7 900-4917-27 Tension Spring
8 400-1000-04 Spring Tension Tab
9 402-3000-11 Track Adjuster Washer
10 400-1000-08 Track Adjuster Bolt Assembly
11 402-3000-13 Track Adjuster Bolt Retainer
12
402-1000-05
Track Assembly - Right Side
(Start 11/17)
Includes: 1 - 12 & 14 - 17
402-2000-05
Track Frame Assembly - Right
Side (Start 11/17)
402-1000-04
Track Assembly - Right Side
(Pre 11/17)
Includes: 1 - 12 & 14 - 17
402-2000-04
Track Frame Assembly - Right
Side (Pre 11/17)
13
402-1000-06
Track Assembly - Left Side
(Start 11/17)
Includes: 1 - 11 & 13 - 17
402-2000-06
Track Frame Assembly - Left
Side (Start 11/17)
402-1000-03
Track Assembly - Left Side
(Pre 11/17)
Includes: 1 - 11 & 13 - 17
402-2000-03
Track Frame Assembly - Left
Side (Pre 11/17)
14 402-3000-10 Drive Hub
15 402-3000-09 Drive Sprocket
16 900-3959-99 Hydraulic Motor With Brake
17 402-3000-12 Track Motor Draw Ring
18 203-2000-80 Track Support
19 203-3003-06 Swing Cylinder Chip Curtain
20 900-4913-46 Chip Curtain Washer
# Part Number Description
21 900-1916-28
Split Bushing -
1” OD x 3/4” x 1/2”
22 203-2000-84 Swing Out Bolt-On Mount
23 900-1902-42
Split Bushing -
1 1/4” OD x 1” ID x 1”
24 203-2001-27 Oil Cooler Cover
25 900-3952-11 Oil Cooler
26 203-1000-64
Oil Cooler Mount & Assembly
(Includes 24 - 27)
27 904-0007-30 Oil Cooler Screen
28 203-2000-53 Manual Holder Mount
29 900-9910-28 Manual Holder
30
203-2001-34 Bumper Ass’y - Tier 4F Engine
203-2000-82 Bumper Ass’y - Pre Tier 4F Engine
31 900-7901-71 Plastic Battery Liner Box
32 900-6900-01 530 CCA Battery
33
900-3959-57
Cutter Wheel Pump Mount -
Kohler Engines Only
900-3959-56
Cutter Wheel Pump Mount -
Briggs & Stratton (Vanguard)
Engines Only
900-3959-75 Pump Mount Access Cover
34 900-3956-12
Cutter Wheel Pump Coupler -
Pump Side - Gasoline Engines
Only
35 900-3956-00
Cutter Wheel Pump Coupler
Spider - Gasoline Engines Only
36 900-1916-35
Cutter Wheel Pump Coupler
- Engine Side - Gasoline
Engines Only
37 See Check Sheet Auxiliary Pump
38 900-3982-94 Cutter Wheel Hydraulic Pump
39 900-6916-26 Engine Isolator
40
900-3937-80 Engine Oil Drain Hose
900-3936-41 Cap for Engine Oil Drain Hose
41 203-2000-49 Pump Engagement Lever
