MODELS 2550/2550T CUTTER WHEEL ARM COMPONENTS
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
# Part Number Description
1 203-2000-35 Chip Pan
2 203-3002-97 Split Chip Curtain - Front
3 203-3002-98 Split Chip Curtain - Middle
4 203-3003-00 Rear Chip Curtain
5 900-4913-46 Chip Curtain Washer
6 203-2000-20 Cutter Wheel Guard
7
203-2000-21
Cutter Wheel Motor Guard
(Start 4/14)
203-2000-57
Cutter Wheel Motor Guard (Pre
4/14)
8 203-3002-71 Stub Shaft Brace
9 203-3002-72 Backer Plate
10 900-1918-00
Split Bushing -
1” OD x 3/4” ID x 1 1/2”
11 900-1918-01
Split Bushing -
1 1/4” OD x 1” ID x 2”
12
203-2000-68
Cutter Wheel Arm Assembly
(Start 4/14)
203-2000-02
Cutter Wheel Arm Assembly
(Pre 4/14)
# Part Number Description
13 900-3958-80 Swing Cylinder
14 900-3934-20 Cylinder Pin - 1” x 2 7/8”
15 900-4901-47 3/4” Mill Carb Washer
16 203-3000-63 Cutter Wheel Lift Cylinder Pin
17 900-4911-75 3/16” x 2” Cotter Pin
18 900-3940-29 Cutter Wheel Lift Cylinder
19 900-4909-08 1”-8NC Slotted Hex Nut
20 900-4904-46 1” Mill Carb Washer
21 900-1902-42
Split Bushing -
1 1/4” OD x 1” ID x 1”
22 203-3000-46 Up / Down Main Pivot Pin
23 203-3000-79 Pin Retainer Washer
24 203-2000-09 Lower Pivot Pin
25 203-2000-10 Upper Pivot Pin
26 900-1912-83
Split Bushing -
1” OD x 3/4” ID x 2”
27 203-2000-01 Swing Pivot Assembly
28 900-4917-49 Cutter Wheel Lock Pin
