Bandit 2550 - Steering Components

Bandit
77
Copyright 4/21
MODELS 2550/2550T
# Part Number Description
1 900-4909-42 1/2”-20NF Lug Nut
2
900-5909-22
18” x 8.50” - 10” Tire & White,
5-Bolt Rim (Specify Left or Right)
900-5909-20 18” x 8.50” - 10” Tire Only
900-5909-21 10” x 6” White, 5-Bolt Rim
3
900-3947-21 Hydraulic Motor Without Brake
900-3938-50 1”-20UNEF Hex Slotted Nut
4
992-1000-30 Wheel Hub Assembly
900-5905-97 1/2”-20NF Stud Only
5 203-2001-56 Steering Mount - Left Side
6 203-2000-03 Pivot Steering Mount
7 203-2001-57 Steering Mount - Right Side
8 900-3937-68 Steering Cylinder
9
204-1000-38
Steering Tie Rod Assembly
(Start 1/20) Includes 10 & 11
203-1000-03
Steering Tie Rod Assembly
(Pre 1/20) Includes 10 & 11
10
900-4903-39 5/8”-11NC Lock Nut (Start 1/20)
900-4906-84 1/2”-13NC Lock Nut (Pre 1/20)
11
900-4928-62
Shoulder Bolt -
3/4” x 5/8”-11NC (Start 1/20)
900-4920-00
Shoulder Bolt -
5/8” x 1/2”-13NC Pre 1/20)
12 900-4900-80
1”-8NC Nylon Insert Hex Lock
Nut
# Part Number Description
13 900-1919-25
Split Bushing -
1 1/4” OD x 1” ID x 1/2”
14 900-4920-54
1”-8NC x 5 1/2” Special Hex
Head Bolt
15 900-1902-50
Split Bushing -
1 1/4” OD x 1” ID x 1 1/2”
16 993-200023 Steering Cylinder Pin - 4” Long
17 993-200022 Steering Cylinder Pin - 5 1/8”
18 900-4914-16 Lynch Pin
19 900-4907-19 Flat Washer
20 900-1908-37
Split Bushing -
1 3/4” x OD x 1 1/2” ID x 1 1/2”
21 203-2001-53 Steering Pivot Pin
22 900-4918-92 Castle Nut
23 900-4911-75 Cotter Pin
24
203-2000-06 Spindle Mount
900-5905-37 Hub Assembly
021-041-01 Grease Cap for Hub
085-001-00 Rubber Cap for Grease Cap
031-031-02 Inner & Outer Bearing for Hub
031-031-01
Inner & Outer Bearing Cup for
Hub
010-060-00 Inner & Outer Seal for Hub
900-5905-97 1/2”-20NF Stud Only
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
STEERING COMPONENTS
