MODELS 2550/2550T CONTROLS
CONTROL OPERATING PROCEDURES
SWING OUT
1. Travel Speed Control: The travel speed controls the rate the machine approaches the stump. To decrease
the travel speed, turn the control knob clockwise.
2. Swing Speed Control: The swing speed controls the rate the cutter wheel passes through the stump.
To decrease the swing speed, turn the control knob clockwise.
3. Swing Out Lock Pin: Lock the swing out lock pin into the operating position or the transport position.
4. Cutter Wheel On / O󰀨 Switch: Before engaging or disengaging the cutter wheel, make sure the
engine is at an idle. To turn the cutter wheel on, push the switch up. To turn the cutter wheel o󰀨, push
the switch down.
5. Grading Blade Down / Up: To lower the grading blade, push the handle away from the operator. To lift
the cutter wheel, pull the handle towards the operator. The cutter wheel lift is stationary when the handle
is in the center location.
6. Left Track Forward / Reverse: To move the left track forward, push the handle away from the operator.
To reverse the left track, pull the handle towards the operator. The track is stationary when the handle
is in the center location.
7. Right Track Forward / Reverse: To move the right track forward, push the handle away from the operator.
To reverse the right track, pull the handle towards the operator. The track is stationary when the handle
is in the center location.
8. Cutter Down / Up: To lower the cutter wheel, push the handle away from the operator. To lift the grading
blade, pull the handle towards the operator. The grading blade is stationary when the handle is in the
center location.
9. Swing Left / Right: To swing the cutter wheel to the left, push the handle, away from the operator. To
swing the cutter wheel to the right, pull the handle, towards the operator. The swing is stationary when
the handle is in the center location.
10. Emergency Stop: Stops the engine in emergency situations.
11. Power Display: Displays engine information: Temperature, RPMs, Tach / Hour Meter, etc.
12. Ignition Switch: Location varies with di󰀨erent engine options.
