Bandit 2550 - Page 61

Bandit
57
Copyright 4/21
MODELS 2550/2550T
TYPICAL HYDRAULIC RELIEF PRESSURE SETTINGS
TYPICAL HYDRAULIC FLOWS AND RPM SETTINGS
(Approximate, For Reference Only, Engine At Full RPM)
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE RELIEF PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
These typical hydraulic ows and relief pressure settings are with the engine at full RPM. All settings are
subject to change!
NOTICE
NOTICE
HYDRAULICS
HYDRAULICS - 2550
After the initial start-up of the machine and after any replacement of hydraulic components, ttings and
hoses must be re-checked for leaks and clearances.
CAUTION
!
2550 with REMOTE Control Valves
Engine RPM
Cutter
Wheel
RPM
Cutter Wheel
Pump GPM
(LPM)
Auxiliary
Pump GPM
(LPM)
Cutter Wheel PSI
(bar)
Briggs & Stratton 35Hp 3500 2100 20 (75) 4.7 (18) 3500 (241)
Kohler 35Hp 3500 2100 20 (75) 4.7 (18) 3500 (241)
Kubota 44.5Hp 3100 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Gas 3000 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Diesel 2700 1680 17.5 (66) 6.3 (23) 5000-5100 (345-352)
Kohler 49Hp Diesel 2600 1625 17.1 (64) 6.3 (23) 5000-5100 (345-352)
Function Main
PSI (bar)
Charge PSI
(bar)
Cutter Wheel Up &
Down PSI (bar)
Swing PSI
(bar)
Steering PSI
(bar)
Blade PSI
(bar)
2750 (189)
400-420
(27-29)
controlled by MAIN
PRESSURE
2300-2400
(158-165)
2300-2400
(158-165)
2400
(165)
2550 with MANUAL Control Valves
Engine RPM
Cutter
Wheel
RPM
Cutter Wheel
Pump GPM
(LPM)
Auxiliary
Pump GPM
(LPM)
Cutter Wheel PSI
(bar)
Briggs & Stratton 35Hp 3500 2100 20 (75) 4.7 (18) 3500 (241)
Kohler 35Hp 3500 2100 20 (75) 4.7 (18) 3500 (241)
Kubota 44.5Hp 3100 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Gas 3000 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Diesel 2700 1680 17.5 (66) 6.3 (23) 5000-5100 (345-352)
Kohler 49Hp Diesel 2600 1625 17.1 (64) 6.3 (23) 5000-5100 (345-352)
Function Main
PSI (bar)
Charge PSI
(bar)
Cutter Wheel Up
& Down PSI (bar)
Swing PSI
(bar)
Steering PSI
(bar)
Blade PSI
(bar)
2750 (189)
400-420
(27-29)
controlled by MAIN PRESSURE
