MODELS 2550/2550T
TYPICAL HYDRAULIC RELIEF PRESSURE SETTINGS
TYPICAL HYDRAULIC FLOWS AND RPM SETTINGS
(Approximate, For Reference Only, Engine At Full RPM)
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE RELIEF PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
These typical hydraulic ows and relief pressure settings are with the engine at full RPM. All settings are
subject to change!
NOTICE
NOTICE
HYDRAULICS
HYDRAULICS - 2550 TRACK
After the initial start-up of the machine and after any replacement of hydraulic components, ttings and
hoses must be re-checked for leaks and clearances.
CAUTION
!
2550 TRACK with MANUAL Control Valves
Engine RPM
Cutter
Wheel
RPM
Cutter Wheel
Pump GPM
(LPM)
Auxiliary
Pump GPM
(LPM)
Cutter Wheel PSI
(bar)
Kubota 44.5Hp 3100 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Gas 3000 1870 20 (75) 7.6 (28) 5000-5100 (345-352)
Kubota 49Hp Diesel 2700 1680 17.5 (66) 6.3 (23) 5000-5100 (345-352)
Kohler 49Hp Diesel 2600 1625 17.1 (64) 6.3 (23) 5000-5100 (345-352)
Engine
Function Main
(P1) PSI (bar)
Function Main
(P2) PSI (bar)
Charge PSI
(bar)
Left Track
PSI (bar)
Right Track
PSI (bar)
Kubota 44.5Hp 2750 (189) 2750 (189) 400-420 (27-29) 2750 (189) 2750 (189)
Kubota 49Hp Gas 3100 (214) 2750 (189) 400-420 (27-29) 2800 (193) 2800 (193)
Kubota 49Hp Diesel 3000 (207) 2750 (189) 400-420 (27-29) 2800 (193) 2800 (193)
Kohler 49Hp Diesel 3000 (207) 2750 (189) 400-420 (27-29) 2800 (193) 2800 (193)
Swing PSI (bar) Cutter Wheel Up & Down
PSI (bar)
Blade PSI (bar)
controlled by MAIN
PRESSURE “P2”
controlled by MAIN
PRESSURE “P1”
controlled by MAIN
PRESSURE “P1”
To Next Page
