MODELS 2550/2550T
MODEL 2550
FRAME COMPONENTS
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
# Part Number Description
1 900-4913-38 1”-8NC x 5 1/2” Hex Head Bolt
2
900-5909-22
18” x 8.50” - 10” Tire & White,
5-Bolt Rim (Specify Left or Right)
900-5909-20 18” x 8.50” - 10” Tire Only
900-5909-21 10” x 6” White, 5-Bolt Rim Only
3 900-4914-00 1/2”-20NF Lug Nut
4
991-2000-81 Dual Wheel Spacer
991-1000-60 Dual Wheel Spacer Kit
5 991-2000-80 Dual Wheel Hub
6
991-1000-61 Wheel Hub Assembly (4x4)
203-1000-57 Wheel Hub Assembly (2x4)
900-5905-97 1/2”-20NF Stud Only
7
900-3959-99
Hydraulic Motor with Brake
(Start S/N 251210)
900-3947-20 Hydraulic Motor with Brake
8 900-4913-46 Chip Curtain Washer
9 203-3003-06 Swing Cylinder Chip Curtain
10 900-1916-28
Split Bushing -
1” OD x 3/4” ID x 1/2”
11 203-3003-06 Swing Out Bolt-On Mount
12 900-1902-42
Split Bushing -
1 1/4” OD x 1” ID x 1”
13 900-7901-71 Plastic Battery Liner Box
14 900-6900-01 530 CCA Battery
15 203-3001-38 Frame Chip Pan Curtain
16 203-2001-27 Oil Cooler Cover
17 900-3952-11 Oil Cooler
18 203-1000-64
Oil Cooler Mount & Assembly
(Includes 16 - 19)
19 904-0007-30 Oil Cooler Screen
20 900-3955-82 Charge Filter
21
203-2000-60
Bumper Assembly for Gasoline
Engine (Weighted)
203-2001-34
Bumper Assembly for Diesel
Engine
# Part Number Description
22 900-9910-28 Manual Holder
23 203-2000-53 Manual Holder Mount
24
900-3959-57
Cutter Wheel Pump Mount -
Kohler Engines Only
900-3959-56
Cutter Wheel Pump Mount -
Briggs & Stratton (Vanguard)
Engines Only
900-3959-75 Pump Mount Access Cover
25 900-3956-12
Cutter Wheel Pump Coupler -
Pump Side - Gasoline Engines
Only
26 900-3956-00
Cutter Wheel Pump Coupler
Spider - Gasoline Engines Only
27 900-1916-35
Cutter Wheel Pump Coupler
- Engine Side - Gasoline
Engines Only
28 See Check Sheet Auxiliary Pump
29
900-3982-94
Cutter Wheel Hydraulic Pump -
Elec. Engagement (Start 1/17)
900-3955-97
Cutter Wheel Hydraulic Pump -
Manual Engagement (Pre 1/17)
30 900-6916-26 Engine Isolator
31
900-3937-80 Engine Oil Drain Hose
900-3936-41 Cap for Engine Oil Drain Hose
32 203-2000-49 Pump Engagement Lever
33 900-3967-53
Carbon Canister - Gasoline
Engines Only (Not Shown)
