Bandit 75 - Anvil & Hardware Parts

Bandit69
MODEL 75 REPLACEMENT PARTS
ANVIL & HARDWARE
# Part Number Description
1
907-3000-09 Anvil Only - 4 Sided
2
900-4903-54 5/16”-18NC x 1/2” Set Screw
3
900-4906-39
5/16”-18NC x 1 1/2” Hex Head
Bolt
4
900-4910-73 5/16”-18NC Hex Nut
5
900-4924-05 1/2” Mill Carb Washer
6
900-4906-88 1/2” Flat Washer
7
900-4905-43
Anvil Eye Bolt -
1/2”-13NC x 3 1/2”
8
900-4906-86 1/2” Lock Washer
# Part Number Description
9
900-4906-74 1/2”-13NC x 2” Hex Head Bolt
10
900-4906-72
1/2”-13NC x 1 1/2” Hex Head
Bolt
11
900-4906-82 1/2”-13NC Hex Nut
12
900-4906-90 1/2” USS Flat Washer
13
955-300193 Anvil Gauge
14
626-0500-77
Anvil Hardware Only
(Includes 2 - 12)
15
907-2000-07
Anvil & Hardware Kit
(Includes 1 - 12)
Anvil Bolt Torque: 75 ft.-lbs. (102 Nm)
13
3
2
1
4
6
5
7
8
9
5
5
6
6
7
8
11
12
12
11
11
11
12
12
9
8
10
