33
Setup variable ‘EQ 1’ - allows you to set default bass and treble settings for use with all input sources in all audio
modes excluding DVD Audio. Many systems allow only adjustment of bass and treble levels at fixed frequency
points. Your processor allows you to adjust level and frequency to aid in adjusting your room for a flat frequency
response. Set bass and treble to the values you would like have restored into the variable ‘EQ 1’ whenever your
unit comes out of sleep (see Select variable ‘EQ 1’ under OPERATION Equalization).
From Remote From Front Panel Action
1
À(UP) or §(DOWN)
(UP) or (DOWN) move to Bass Frequency
2
(LEFT) or(RIGHT)
VOLUME KNOB set to desired bass frequency
3
À(UP) or §(DOWN)
(UP) or (DOWN) move to Bass Level
4
(LEFT) or(RIGHT)
VOLUME KNOB set to desired bass level
5
À(UP) or §(DOWN)
(UP) or (DOWN) move to Treble Frequency
6
(LEFT) or
(RIGHT)
VOLUME KNOB set to desired treble frequency
7
À(UP) or §(DOWN)
(UP) or (DOWN) move to Treble Level
8
(LEFT) or(RIGHT)
VOLUME KNOB set to desired treble level
9 MENU MENU return to SETUP SYSTEM
Set subwoofer phase - In addition to the subwoofer location adjustment (see Speaker Location above), your
processor has an option to ‘invert the phase’ of the information sent to the subwoofer. This adjustment is
sometimes needed to correct ‘lack of low end’ problems created with the interaction between the subwoofer and
other large speakers in a listening room. The correct subwoofer phase adjustment is the one, which allows the
loudest listening level.
From Remote From Front Panel Action
1
À(UP) or §(DOWN)
(UP) or (DOWN) move to SUBWOOFER PHASE
2
(LEFT) or(RIGHT)
VOLUME KNOB adjust to desired value
3 MENU MENU return to SETUP SPEAKERS
4 MENU MENU return to SETUP SYSTEM
Bass 320.0 HZ
320.0 Hz
SETUP ROOM EQUALIZATION
THX Boundary Gain Comp NO
Test Tone 100.0 Hz Off
Notch 150.0 Hz -20.0 dB
Notch Width 146.4 - 153.6 Hz
Bass 320.0 Hz +4.5 dB
Treble 10.0 kHz -18.0 dB
Subwoofer Phase Normal
next item adjust
MENU system setup
320.0 Hz
SETUP ROOM EQUALIZATION
THX Boundary Gain Comp NO
Test Tone 100.0 Hz Off
Notch 150.0 Hz -20.0 dB
Notch Width 146.4 - 153.6 Hz
Bass 320.0 Hz +4.5 dB
Treble 10.0 kHz -18.0 dB
Subwoofer Phase Normal
next item adjust
MENU system setup
Subwoofer Phase Normal
SUB PHASE normal
